Description

Gnome::Gtk4::Frame is a widget that surrounds its child with a decorative frame and an optional label.

If present, the label is drawn inside the top edge of the frame. The horizontal position of the label can be controlled with .set-label-align().

Gnome::Gtk4::Frame clips its child. You can use this to add rounded corners to widgets, but be aware that it also cuts off shadows.

GtkFrame as GtkBuildable

The Gnome::Gtk4::Frame implementation of the Gnome::Gtk4::R-Buildable interface supports placing a child in the label position by specifying “label” as the “type” attribute of a `<child>` element. A normal content child can be specified without specifying a `<child>` type attribute.

An example of a UI definition fragment with GtkFrame:

CSS nodes

Gnome::Gtk4::Frame has a main CSS node with name “frame”, which is used to draw the visible border. You can set the appearance of the border using CSS properties like “border-style” on this node.

Accessibility

Gnome::Gtk4::Frame uses the GTK_ACCESSIBLE_ROLE_GROUP role.

Class initialization

new

:native-object

Create an object using a native object from elsewhere. See also Gnome::N::TopLevelSupportClass.

multi method new ( N-Object :$native-object! )

new-frame

Creates a new Gnome::Gtk4::Frame, with optional label $label.

If $label is undefined, the label is omitted.

method new-frame ( Str $label --> Gnome::Gtk4::Frame \)

• $label; the text to use as the label of the frame.

Methods

get-child

Gets the child widget of $frame.

method get-child (--> N-Object )

Return value; the child widget of $frame.

get-label

Returns the frame labels text.

If the frame's label widget is not a Gnome::Gtk4::Label, undefined is returned.

method get-label (--> Str )

Return value; the text in the label, or undefined if there was no label widget or the label widget was not a Gnome::Gtk4::Label. This string is owned by GTK and must not be modified or freed..

get-label-align

Retrieves the X alignment of the frame’s label.

method get-label-align (--> Num )

Return value; the frames X alignment.

get-label-widget

Retrieves the label widget for the frame.

method get-label-widget (--> N-Object )

Return value; the label widget.

set-child

Sets the child widget of $frame.

method set-child ( N-Object() $child )

• $child; the child widget.

set-label

Creates a new Gnome::Gtk4::Label with the $label and sets it as the frame's label widget.

method set-label ( Str $label )

• $label; the text to use as the label of the frame.

set-label-align

Sets the X alignment of the frame widget’s label.

The default value for a newly created frame is 0.0.

method set-label-align ( Num() $xalign )

• $xalign; The position of the label along the top edge of the widget. A value of 0.0 represents left alignment; 1.0 represents right alignment..

set-label-widget

Sets the label widget for the frame.

This is the widget that will appear embedded in the top edge of the frame as a title.

method set-label-widget ( N-Object() $label-widget )

• $label-widget; the new label widget.
