Description

A Gnome::Gtk4::FlowBox puts child widgets in reflowing grid.

For instance, with the horizontal orientation, the widgets will be arranged from left to right, starting a new row under the previous row when necessary. Reducing the width in this case will require more rows, so a larger height will be requested.

Likewise, with the vertical orientation, the widgets will be arranged from top to bottom, starting a new column to the right when necessary. Reducing the height will require more columns, so a larger width will be requested.

The size request of a Gnome::Gtk4::FlowBox alone may not be what you expect; if you need to be able to shrink it along both axes and dynamically reflow its children, you may have to wrap it in a Gnome::Gtk4::ScrolledWindow to enable that.

The children of a Gnome::Gtk4::FlowBox can be dynamically sorted and filtered.

Although a Gnome::Gtk4::FlowBox must have only Gnome::Gtk4::FlowBoxChild children, you can add any kind of widget to it via .insert(), and a Gnome::Gtk4::FlowBoxChild widget will automatically be inserted between the box and the widget.

Also see Gnome::Gtk4::ListBox.

CSS nodes

Gnome::Gtk4::FlowBox uses a single CSS node with name flowbox. Gnome::Gtk4::FlowBoxChild uses a single CSS node with name flowboxchild. For rubberband selection, a subnode with name rubberband is used.

Accessibility

Gnome::Gtk4::FlowBox uses the GTK_ACCESSIBLE_ROLE_GRID role, and Gnome::Gtk4::FlowBoxChild uses the GTK_ACCESSIBLE_ROLE_GRID_CELL role.

Class initialization

new

:native-object

Create an object using a native object from elsewhere. See also Gnome::N::TopLevelSupportClass.

multi method new ( N-Object :$native-object! )

new-flowbox

Creates a Gnome::Gtk4::FlowBox.

method new-flowbox ( --> Gnome::Gtk4::FlowBox \)

Methods

append

Adds $child to the end of $self.

If a sort function is set, the widget will actually be inserted at the calculated position.

See also: .insert().

method append ( N-Object() $child )

• $child; the Gnome::Gtk4::Widget to add.

bind-model This function is not yet available

Binds $model to $box.

If $box was already bound to a model, that previous binding is destroyed.

The contents of $box are cleared and then filled with widgets that represent items from $model. $box is updated whenever $model changes. If $model is undefined, $box is left empty.

It is undefined to add or remove widgets directly (for example, with .insert()) while $box is bound to a model.

Note that using a model is incompatible with the filtering and sorting functionality in Gnome::Gtk4::FlowBox. When using a model, filtering and sorting should be implemented by the model.

method bind-model ( N-List() $model, &create-widget-func, gpointer $user-data, … )

• $model; the Gnome::Gio::R-ListModel to be bound to $box.

• &create-widget-func; a function that creates widgets for items. Tthe function must be specified with following signature; :( gpointer $item, gpointer $user-data -- N-Object )>.

• $user-data; user data passed to $create-widget-func.

• user-data-free-func; function for freeing $user-data. Note that each argument must be specified as a type followed by its value!

get-activate-on-single-click

Returns whether children activate on single clicks.

method get-activate-on-single-click (--> Bool )

Return value; True if children are activated on single click, False otherwise.

get-child-at-index

Gets the nth child in the $box.

method get-child-at-index ( Int() $idx --> N-Object )

• $idx; the position of the child.

Return value; the child widget, which will always be a Gnome::Gtk4::FlowBoxChild or undefined in case no child widget with the given index exists..

get-child-at-pos

Gets the child in the ( $x, $y) position.

Both $x and $y are assumed to be relative to the origin of $box.

method get-child-at-pos ( Int() $x, Int() $y --> N-Object )

• $x; the x coordinate of the child.

• $y; the y coordinate of the child.

Return value; the child widget, which will always be a Gnome::Gtk4::FlowBoxChild or undefined in case no child widget exists for the given x and y coordinates..

get-column-spacing

Gets the horizontal spacing.

method get-column-spacing (--> UInt )

Return value; the horizontal spacing.

get-homogeneous

Returns whether the box is homogeneous.

method get-homogeneous (--> Bool )

Return value; True if the box is homogeneous..

get-max-children-per-line

Gets the maximum number of children per line.

method get-max-children-per-line (--> UInt )

Return value; the maximum number of children per line.

get-min-children-per-line

Gets the minimum number of children per line.

method get-min-children-per-line (--> UInt )

Return value; the minimum number of children per line.

get-row-spacing

Gets the vertical spacing.

method get-row-spacing (--> UInt )

Return value; the vertical spacing.

get-selected-children

Creates a list of all selected children.

method get-selected-children (--> N-List )

Return value; A Gnome::Glib::N-List containing the Gnome::Gtk4::Widget for each selected child. Free with g_list_free() when done..

get-selection-mode

Gets the selection mode of $box.

method get-selection-mode (--> GtkSelectionMode )

Return value; the enumeration GtkSelectionMode defined in Gnome::Gtk4::T-enums.

insert

Inserts the $widget into $box at $position.

If a sort function is set, the widget will actually be inserted at the calculated position.

If $position is -1, or larger than the total number of children in the $box, then the $widget will be appended to the end.

method insert ( N-Object() $widget, Int() $position )

• $widget; the Gnome::Gtk4::Widget to add.

• $position; the position to insert $child in.

invalidate-filter

Updates the filtering for all children.

Call this function when the result of the filter function on the $box is changed due to an external factor. For instance, this would be used if the filter function just looked for a specific search term, and the entry with the string has changed.

method invalidate-filter ( )

invalidate-sort

Updates the sorting for all children.

Call this when the result of the sort function on $box is changed due to an external factor.

method invalidate-sort ( )

prepend

Adds $child to the start of $self.

If a sort function is set, the widget will actually be inserted at the calculated position.

See also: .insert().

method prepend ( N-Object() $child )

• $child; the Gnome::Gtk4::Widget to add.

remove

Removes a child from $box.

method remove ( N-Object() $widget )

• $widget; the child widget to remove.

remove-all

Removes all children from $box.

This function does nothing if $box is backed by a model.

method remove-all ( )

select-all

Select all children of $box, if the selection mode allows it.

method select-all ( )

select-child

Selects a single child of $box, if the selection mode allows it.

method select-child ( N-Object() $child )

• $child; a child of $box.

selected-foreach

Calls a function for each selected child.

Note that the selection cannot be modified from within this function.

method selected-foreach ( &func, gpointer $data )

• &func; the function to call for each selected child. Tthe function must be specified with following signature; :( N-Object $box, N-Object $child, gpointer $user-data ).

• $data; user data to pass to the function.

set-activate-on-single-click

If $single is True, children will be activated when you click on them, otherwise you need to double-click.

method set-activate-on-single-click ( Bool() $single )

• $single; True to emit child-activated on a single click.

set-column-spacing

Sets the horizontal space to add between children.

method set-column-spacing ( UInt() $spacing )

• $spacing; the spacing to use.

set-filter-func This function is not yet available

By setting a filter function on the $box one can decide dynamically which of the children to show.

For instance, to implement a search function that only shows the children matching the search terms.

The $filter-func will be called for each child after the call, and it will continue to be called each time a child changes (via .changed() in class Gnome::Gtk4::FlowBoxChild) or when .invalidate-filter() is called.

Note that using a filter function is incompatible with using a model (see .bind-model()).

method set-filter-func ( &filter-func, gpointer $user-data, … )

• &filter-func; callback that lets you filter which children to show. Tthe function must be specified with following signature; :( N-Object $child, gpointer $user-data -- gboolean )>.

• $user-data; user data passed to $filter-func.

• destroy; destroy notifier for $user-data. Note that each argument must be specified as a type followed by its value!

set-hadjustment

Hooks up an adjustment to focus handling in $box.

The adjustment is also used for autoscrolling during rubberband selection. See .get-hadjustment() in class Gnome::Gtk4::ScrolledWindow for a typical way of obtaining the adjustment, and .set-vadjustment() for setting the vertical adjustment.

The adjustments have to be in pixel units and in the same coordinate system as the allocation for immediate children of the box.

method set-hadjustment ( N-Object() $adjustment )

• $adjustment; an adjustment which should be adjusted when the focus is moved among the descendents of $container.

set-homogeneous

Sets whether or not all children of $box are given equal space in the box.

method set-homogeneous ( Bool() $homogeneous )

• $homogeneous; True to create equal allotments, False for variable allotments.

set-max-children-per-line

Sets the maximum number of children to request and allocate space for in $box’s orientation.

Setting the maximum number of children per line limits the overall natural size request to be no more than $n-children children long in the given orientation.

method set-max-children-per-line ( UInt() $n-children )

• $n-children; the maximum number of children per line.

set-min-children-per-line

Sets the minimum number of children to line up in $box’s orientation before flowing.

method set-min-children-per-line ( UInt() $n-children )

• $n-children; the minimum number of children per line.

set-row-spacing

Sets the vertical space to add between children.

method set-row-spacing ( UInt() $spacing )

• $spacing; the spacing to use.

set-selection-mode

Sets how selection works in $box.

method set-selection-mode ( GtkSelectionMode $mode )

• $mode; the new selection mode.

set-sort-func This function is not yet available

By setting a sort function on the $box, one can dynamically reorder the children of the box, based on the contents of the children.

The $sort-func will be called for each child after the call, and will continue to be called each time a child changes (via .changed() in class Gnome::Gtk4::FlowBoxChild) and when .invalidate-sort() is called.

Note that using a sort function is incompatible with using a model (see .bind-model()).

method set-sort-func ( &sort-func, gpointer $user-data, … )

• &sort-func; the sort function. Tthe function must be specified with following signature; :( N-Object $child1, N-Object $child2, gpointer $user-data -- gint )>.

• $user-data; user data passed to $sort-func.

• destroy; destroy notifier for $user-data. Note that each argument must be specified as a type followed by its value!

set-vadjustment

Hooks up an adjustment to focus handling in $box.

The adjustment is also used for autoscrolling during rubberband selection. See .get-vadjustment() in class Gnome::Gtk4::ScrolledWindow for a typical way of obtaining the adjustment, and .set-hadjustment() for setting the horizontal adjustment.

The adjustments have to be in pixel units and in the same coordinate system as the allocation for immediate children of the box.

method set-vadjustment ( N-Object() $adjustment )

• $adjustment; an adjustment which should be adjusted when the focus is moved among the descendents of $container.

unselect-all

Unselect all children of $box, if the selection mode allows it.

method unselect-all ( )

unselect-child

Unselects a single child of $box, if the selection mode allows it.

method unselect-child ( N-Object() $child )

• $child; a child of $box.

Signals

activate-cursor-child

Emitted when the user activates the $box.

This is a [keybinding signal](class.SignalAction.html).

method handler (
  Int :$_handle_id,
  N-GObject :$_native-object,
  Gnome::Gtk4::FlowBox :$_widget,
  *C<user>-options
)

• $_handle_id; The registered event handler id.

• $_native-object; The native object provided by the Raku object which registered this event. This a native Gnome::Gtk4::FlowBox object.

• $_widget; The object which registered the signal. User code may have left the object going out of scope.

• user-options; A list of named arguments provided at the .register-signal() method from Gnome::GObject::Object.

child-activated

Emitted when a child has been activated by the user.

method handler (
  N-Object $child,
  Int :$_handle_id,
  N-GObject :$_native-object,
  Gnome::Gtk4::FlowBox :$_widget,
  *C<user>-options
)

• $child; the child that is activated.

• $_handle_id; The registered event handler id.

• $_native-object; The native object provided by the Raku object which registered this event. This a native Gnome::Gtk4::FlowBox object.

• $_widget; The object which registered the signal. User code may have left the object going out of scope.

• user-options; A list of named arguments provided at the .register-signal() method from Gnome::GObject::Object.

move-cursor

Emitted when the user initiates a cursor movement.

This is a [keybinding signal](class.SignalAction.html). Applications should not connect to it, but may emit it with g_signal_emit_by_name() if they need to control the cursor programmatically.

The default bindings for this signal come in two variants, the variant with the Shift modifier extends the selection, the variant without the Shift modifier does not. There are too many key combinations to list them all here.

• <kbd>←</kbd>, <kbd>→</kbd>, <kbd>↑</kbd>, <kbd>↓</kbd> move by individual children

• <kbd>Home</kbd>, <kbd>End</kbd> move to the ends of the box

• <kbd>PgUp</kbd>, <kbd>PgDn</kbd> move vertically by pages

method handler (
   $step,
  gint $count,
  gboolean $extend,
  gboolean $modify,
  Int :$_handle_id,
  N-GObject :$_native-object,
  Gnome::Gtk4::FlowBox :$_widget,
  *C<user>-options
  --> gboolean
)

• $step; the granularity of the move, as a enumeration GtkMovementStep defined in Gnome::Gtk4::T-enums.

• $count; the number of $step units to move.

• $extend; whether to extend the selection.

• $modify; whether to modify the selection.

• $_handle_id; The registered event handler id.

• $_native-object; The native object provided by the Raku object which registered this event. This a native Gnome::Gtk4::FlowBox object.

• $_widget; The object which registered the signal. User code may have left the object going out of scope.

• user-options; A list of named arguments provided at the .register-signal() method from Gnome::GObject::Object.

Return value; True to stop other handlers from being invoked for the event. False to propagate the event further.

select-all

Emitted to select all children of the box, if the selection mode permits it.

This is a [keybinding signal](class.SignalAction.html).

The default bindings for this signal is <kbd>Ctrl</kbd>-<kbd>a</kbd>.

method handler (
  Int :$_handle_id,
  N-GObject :$_native-object,
  Gnome::Gtk4::FlowBox :$_widget,
  *C<user>-options
)

• $_handle_id; The registered event handler id.

• $_native-object; The native object provided by the Raku object which registered this event. This a native Gnome::Gtk4::FlowBox object.

• $_widget; The object which registered the signal. User code may have left the object going out of scope.

• user-options; A list of named arguments provided at the .register-signal() method from Gnome::GObject::Object.

selected-children-changed

Emitted when the set of selected children changes.

Use .selected-foreach() or .get-selected-children() to obtain the selected children.

method handler (
  Int :$_handle_id,
  N-GObject :$_native-object,
  Gnome::Gtk4::FlowBox :$_widget,
  *C<user>-options
)

• $_handle_id; The registered event handler id.

• $_native-object; The native object provided by the Raku object which registered this event. This a native Gnome::Gtk4::FlowBox object.

• $_widget; The object which registered the signal. User code may have left the object going out of scope.

• user-options; A list of named arguments provided at the .register-signal() method from Gnome::GObject::Object.

toggle-cursor-child

Emitted to toggle the selection of the child that has the focus.

This is a [keybinding signal](class.SignalAction.html).

The default binding for this signal is <kbd>Ctrl</kbd>-<kbd>Space</kbd>.

method handler (
  Int :$_handle_id,
  N-GObject :$_native-object,
  Gnome::Gtk4::FlowBox :$_widget,
  *C<user>-options
)

• $_handle_id; The registered event handler id.

• $_native-object; The native object provided by the Raku object which registered this event. This a native Gnome::Gtk4::FlowBox object.

• $_widget; The object which registered the signal. User code may have left the object going out of scope.

• user-options; A list of named arguments provided at the .register-signal() method from Gnome::GObject::Object.

unselect-all

Emitted to unselect all children of the box, if the selection mode permits it.

This is a [keybinding signal](class.SignalAction.html).

The default bindings for this signal is <kbd>Ctrl</kbd>-<kbd>Shift</kbd>-<kbd>a</kbd>.

method handler (
  Int :$_handle_id,
  N-GObject :$_native-object,
  Gnome::Gtk4::FlowBox :$_widget,
  *C<user>-options
)

• $_handle_id; The registered event handler id.

• $_native-object; The native object provided by the Raku object which registered this event. This a native Gnome::Gtk4::FlowBox object.

• $_widget; The object which registered the signal. User code may have left the object going out of scope.

• user-options; A list of named arguments provided at the .register-signal() method from Gnome::GObject::Object.
